6
Introduction Control Buttons
Weight:
Without batteries
1.42 lbs
643.5 g
Operating Temperature Range:
14 to 104°F
-10 to 40°C
Storage Temperature Range:
-4 to 149°F
-20 to 65°C
Data Buffer
240 data frames (values per parameter)
Communication Protocols
Your ETHOS scan tool supports the following OBD-II/EOBD communications protocols:
SAE J1850 (VPW)
SAE J1850 (PWM)
ISO 9141-2
ISO 14230-4 (KWP 2000)
ISO 15765-4 (CAN)
In addition, the optional vehicle communications software allows you to access “enhanced”
diagnostic information for specific vehicle manufacturers.
2.3 Control Buttons
The scan tool has the following control buttons (Figure 2-2 on page 4):
• S (function)
• N/x (back)
• Y/a (accept)
• b (Up)
• d (Down)
• e (Left)
• c (Right)
• Power
2.3.1 S Button
The S button can be customized to perform different functions. See “S Button” on page 33 for
additional information.
