Chapter 2 Introduction
The ETHOS™ (Figure 2-1) scan tool uses Vehicle Communication Software to provide
vehicle-specific diagnostic trouble codes (DTCs) and datastream information for various
vehicle control systems such as engine, transmission, antilock brake system (ABS) and more.
Your scan tool can also graph live data parameters, record data, clear diagnostic trouble
codes (DTCs) from the vehicle electronic control module (ECM) memory, and reset the
vehicle malfunction indicator lamp (MIL).
Contact your sales representative for availability of software add-ons and upgrades.
Figure 2-1
ETHOS™ scan tool
2.1 Functional Description
This section illustrates external features, ports and connectors of the ETHOS™.

Snap-On ETHOS Specifications

General

Touchscreen	Yes
Display Resolution	1280 x 800
Operating System	Android
Connectivity	Wi-Fi, Bluetooth
Battery Life	8 hours
Compatibility	OBD-II
Software Updates	Regular updates
