Operations Using Tools
5.6 Using Tools
The Tools button provides access to system information and various system controls. The
tools options are discussed in the following sections:
• “S Button” on page 33
• “Units” on page 34
• “Setup” on page 34
• “Sys (System Information)” on page 35
• “Update from CF” on page 36
Figure 5-19
Sample Tools menu
5.6.1 S Button
Selecting S button allows you to change tool settings, which lets you perform the set function
with a single button push. Possible function assignments include:
• Brightness—adjusts the backlighting on the display.
• Print Page—sends the current page, which includes the complete list of data parameters,
to the printer.
• Print Screen—prints only the data currently being displayed on the screen.
• Save Movie—works like the Save button in the data display toolbar. See “Saving” on
page 31 for details.
• Save Screen—saves data displayed on the current screen to tool memory.
• Show S Menu Shortcuts—opens this menu so you can quickly reconfigure the button
setting.
• Toggle Record/Pause—works as the Pause/Record button when viewing data. See
“Pausing Data Collection” on page 27 for details.
z To assign a function to the S button:
1. Select Tools > S.
2. Select a function from the list (Figure 5-19).
The selection is indicated by a check mark.
3. Press N/x to return to the main menu.
i
SetupUnitsS
Tools Menu
Brightness
Print Screen
Freeze/Run Toggle
Print Page
Save Screen
Save Movie
Show S Menu
Sys
To Next Page
