23
Operations Selecting a System
Figure 5-4 Sample Previous Vehicles and Data list
z To select from the previous vehicles and data list
1. Select Previous Vehicles and Data from the menu.
A list of the last 20 vehicles tested displays in the main body of the screen (Figure 5-4).
The Restore Data and Delete Data selections on the toolbar open a list of files that have
been saved to tool memory.
2. Select Restore Data, or Delete Data to open a list of saved files (Figure 5-5).
Figure 5-5
Sample Restore Data list
File names include the vehicle ID, date, and time.
a. If a selection is made from Restore Data or Delete Data, the movie file opens, or is
erased. A confirmation message must be accepted before files are deleted.
b. If a selection is made from Last 20, a vehicle ID confirmation screen displays after the
software loads. Verify the ID.
3. Press Y/a to continue.
A connection message displays.
4. Connect the data cable to the vehicle, then press Y/a.
The menu for the last system tested on the selected vehicle displays.
5.3 Selecting a System
You must select the vehicle control system you wish to test (Figure 5-6).
DeleteRestoreLast 20
Previous Vehicles and Data
2004 (10th VIN = 4) S80 2.3L 5CYL TURBO ...
2002 210 (E-SERIES) 210.065 (E-SERIES) ...
2004 HONDA CIVI 1.6L D16V
2000 HONDA S200 2.0L F20C
2001 (10th VIN = 1) NEW BEETLE 1.6 MPI ...
1999 5-SERIES [E39] 2.8L 24V MPI CAT =...
2002 (11th VIN Character = 2) FOCU 1.4L ...
2000 TOYOTA RAV4 1.8L 1ZZ
DeleteRestoreLast 20
Restore
09:09:2008 09:13 000000002
2002 210 (E-SERIES) 210.065 ...
09:09:2008 11:35 000000003
2004 5-SERIES [E39] 2.8L 24V ...
09:09:2008 14:12 000000003
2000 (11th VIN Character = 2) FOCU 1.4L
09:09:2008 08:17 000000001
2005 (10th VIN = 4) S80 2.3L 5 ...
