Snap-On MODIS Edge User Manual

122
Tools Tools Menu
Touch Screen Calibration
Calibrating the touch screen maintains the accuracy of the touch-sensitive display.
IMPORTANT:
To avoid serious damage to the diagnostic tool, always complete the touch screen calibration
sequence once it has begun. Never turn off the diagnostic tool while a screen calibration is
in process.
z To calibrate the touch screen:
1. Select Tools from the Home screen to open the menu.
2. Select Settings from the menu.
3. Select Touch Calibration from the menu.
The calibration screen opens (Figure 8-6).
Figure 8-6 Touch screen calibration
4. Select each box on the screen as it displays.
The display returns to the Settings menu once the screen calibration procedure is complete.
Time Zone
This option opens a menu of time zone settings. Scroll to highlight, then select the local time zone.
The display returns to the Settings menu once a time zone is selected.
:$51,1*'RQRWSRZHUWKHWRRORIIXQWLOWKH7RXFK
&DOLEUDWLRQKDVEHHQFRPSOHWHGVXFFHVVIXOO\
728&+6&5((1&$/,%5$7,21
728&+%2;,1833(5/()7&251(5
