Scope Multimeter Operation and Controls
Cursor Measurements Panel
When the cursors are turned on, the Refresh, Min, Live, Max display panel is switched off and
replaced by the Cursor Measurements Panel.
The cursor measurements panel displays the following signal and cursor measurements:
• Signal amplitude at two points
• Signal amplitude difference (delta) between two points
• Cursor position in time at two points
• Difference (delta) in time between the cursors
• Frequency - frequency of the signal for the time period between cursor 1 and 2
The cursor measurements panel contains values for each channel in two displays.
The amplitude and delta display is provided in the channel specific colour and includes:
– Cursor 1 - signal amplitude at cursor 1 position
– Cursor 2 - signal amplitude at cursor 2 position
– Delta - signal amplitude difference between cursor 1 and 2
The time and delta display is gray in colour and includes:
– Cursor 1 - cursor position in time at cursor 1
– Cursor 2 - cursor position in time at cursor 2
– Delta - difference in time between cursor 1 and 2
– Frequency - the frequency value (Hz) of the signal for the time period between cursor 1
and 2
i Frequency is the number of times a signal repeats itself per second and is measured in hertz (Hz).
The frequency value displayed, is the inverse of the Delta value, and can also be calculated as 1
divided by Delta. The frequency value (Hz) shown is automatically calculated by the scope.
Example 1: Delta = 20.46ms, to get frequency divide 1 by .02046 (1/.02046 = 48.87Hz)
Example 2: Delta = 2.53ms, to get frequency divide 1 by .00253 (1/.00253 = 395.27Hz)
Use applicable decimal point placement during division as the Delta value changes.
5.5.4 Secondary Ignition Testing
The lab scope function can be used to display secondary ignition waveforms for conventional and
select CIC and COP systems. To display secondary ignition waveforms, optional secondary
ignition coil adaptor(s) and a coil adaptor lead assembly are required.
Contact your sales representative to purchase the optional adaptor leads and/or Secondary
Ignition Clip-on or COP/CIC adaptors.
• Adaptor lead assembly needed:
– Secondary Coil Adaptor Lead Assembly - connects the diagnostic tool to a secondary
ignition adaptor (yellow and black scope connectors and black RCA type adaptor
connector). See Secondary Ignition Coil Adaptor Lead and Clip-on Adaptor (optional)‚ on
page 58.
• Secondary Ignition Adaptors available:
