47
OBD-II/EOBD OBD-II/EOBD Menu
All service modes are not supported by all vehicles, so the available menu selections will vary.
Figure 4-5 Service mode menu
4. Select a test to continue.
Readiness Monitors
Use this menu item to check the readiness of the monitoring system. Monitors not supported will
display “not supported”. Scroll, if needed, to view the entire list of monitors (Figure 4-3). Selecting
Readiness Monitors opens a submenu with two choices:
• Monitors Complete Since DTC Cleared—displays the results of all monitor tests that have
run since the last time the vehicle electronic control module (ECM) memory was cleared.
• Monitors Complete This Cycle—displays only the results of monitor tests that ran during the
current drive cycle, they reset when the ignition is switched off.
MIL Status
This item is used to check the current condition of the malfunction indicator lamp (MIL). Additional
information, such as which ECM commanded the MIL on and the distance driven while the MIL is
on (if supported), can also be displayed. The MIL Status report can also be saved as part of the
vehicle records.
Fast-Track Troubleshooter
Fast-Track® Troubleshooter is a database of experience-based repair strategies and information,
that has been compiled and validated by top-notch technicians. The Troubleshooter system
simplifies the diagnosis process, as it contains information on virtually all common diagnostic
trouble code (DTC) problems and driveability symptoms for most vehicles covered by the vehicle
communication software.
