Snap-On VERDICT D7 User Manual

4
Introduction D7 Display Device
1— USB (universal serial bus) Ports (2)
2— Head Phone Jack
3— Microphone Jack
4— DC Power Supply Input Port
5— SD (secure digital) Card Port
6— Mini USB Client Port
Figure 2-2 Model D7 side views
1— Battery Compartment Cover
2— Kennsington Lock (standard security device connection, device not included)
3— Stylus
4— Camera Lens
5— Collapsible Stand (closed)
Figure 2-3 Model D7 back view






/HIW6LGH 5LJKW6LGH



Snap-On VERDICT D7 Specifications

General

Brand	Snap-On
Model	VERDICT D7
Category	Diagnostic Equipment
Language	English
