Snap-On VERDICT D7 User Manual

127
Chapter 15 Maintenance
This section covers how to care for your VERDICT Diagnostic Platform components.
15.1 D7 Display Device
This section covers how to care for your D7 Display Device.
15.1.1 Cleaning the Touch Screen
The touch screen can be cleaned with a soft cloth and alcohol or a mild window cleaner.
IMPORTANT:
Do not use any abrasive cleansers or automotive chemicals on the touch screen.
15.1.2 Calibrating the Touch Screen
The touch screen can be calibrated for accuracy using the PenMount (PM) utility of the unit.
z To calibrate the touch screen:
1. From the Windows toolbar select Start > PenMount Control Panel.
Figure 15-1 Launching the calibration program
2. In the PM Control Panel; highlight the PenMount 6000 RS232 and select Configure.
3. Select one of two calibration options:
