133
Maintenance SCAN MODULE
Figure 15-7 sample WEEE logo
i Always dispose of materials according to local regulations.
Contact your sales representative for details.
15.1.5 Operating System Restore
Snap-on System Restore is a hard disk drive recovery program that allows you recover the hard
disk drive files in the event of a failure. Running the program replaces all of the C drive data with
the original factory data. Be aware, all new or modified files on the C drive will be lost.
The directional arrow buttons on the D7 Display Device are used to navigate when performing a
system restore. Use the Enter button to make selections.
z To restore the operating system
1. Power on the D7 Display Device.
2. Wait for the “Press Up Arrow to run Snap-on System Restore” message to display, then Press
the Up Arrow button.
A progress indicator displays while the program loads.
3. Select OK from the confirmation message.
A progress indicator displays while the files are being restored.
4. Select OK from the confirmation message.
The D7 Display Device shuts down, then reboots and the system recovery portion of the
operation begins. Follow any on-screen prompts.
The D7 Display Device shuts down and reboots a second time. When the VERDICT Home
screen displays, the procedure is complete and the D7 Display Device is ready for use.
15.2 SCAN MODULE
This section covers how to care for your SCAN MODULE.
15.2.1 Cleaning and Inspecting the SCAN MODULE
When using the SCAN MODULE, make sure to do the following:
• Check the housing, wiring, and connectors for dirt and damage before and after each use.
• At the end of each work day, wipe the housing, wiring, and connectors clean with a slightly
damp cloth.
