BTP-M300 Service Manual
- 43 -
Appendix 3 EEPROM setting table
Address
(HEX)
Instruction Value range and description
04 Print width 0: 76mm,1: 69.5mm,2: 57.5mm
06 Print speed 416-1000 steps/second
12 Paper type 0: Continuous paper, 1: Marked paper
14 CR(0x0D)command mode 0: Paper not feed, 1: CR equivalent LF
16 Baud rate 0: 9600,1: 19200,2: 38400,3: 57600
17 Data bits 7: 7bits, 8: 8 bits
19 Stop bit(s) 1: 1 bit, 2: 2 bits
1B Parity checkout 0: None, 1: odd, 2: even
7D Receiving buffer size 0: 4096Byte, 1: 40Byte
2A Distance from print head to cutter Indicated by feeding steps
2C Distance from sensor to print head Indicated by feeding steps
2E Top limitation of mark length Indicated by feeding steps
30
Cutter enabled 0: Disabled, 1: Enabled
35
Distance between print position to mark Indicated by feeding steps
37
Distance between cut position to mark Indicated by feeding steps
40 Serial software handshaking
0: Disable software handshaking;
1: Enable software handshaking
44 Stop printing when paper near end
0: Does not stop printing when paper near end;
1: Stop printing when paper near end
58 Buzzer enabled 1: Enabled 0: Disabled
7E Sending data when powered on 0: disable1: enable
User can configure EEPROM by command:
[Format] ASCII ESC s B E a1 a2 data1 data2 n
Hex 1B 73 42 45 92 9A data1 data2 n
Decimal 27 115 66 69 146 154 data1 data2 n
[Range] 0≤n≤127
a1 = 92h
a2 = 9Ah
[Description] Write a WORD type data to EEPROM address specified by n, data1 is low-bit data and
data2 is high-bit data. After changing the EEPROM configuration, the configuration will be
effective only after restarting the printer.
