BTP-M300 Service Manual
- 50 -
Appendix 6 Part list
Item Part No. Drawing No. Name Q'ty Remarks
1.
8005- 904688 BTP-M300.01.02.16R Pressure spring of start spanner 1
2.
8201-928543 BTP-M300.02.02R
Spanner of top cover 1
8201-928584 BTP-M300.02.02R
3.
8201- 928542 BTP-M300.02.01R
Top cover
1 Black
8201- 928583 BTP-M300.02.01R 1 White
4.
8201-905234 BTP-R580.01.10R
Insertion of top cover
1 Black
8201-905233 BTP-R580.01.10R 1 White
5.
8201-928545 BTP-M300.02.04R
Middle cover
1 Black
8201-928586 BTP-M300.02.04R 1 White
6.
8201-928546 BTP-M300.02.05R
Bottom cover
1 Black
8201- 928587 BTP-M300.02.05R 1 White
7.
8205-900247 BTP-2002CP .BS.01RⅡ Cutter label 1
8.
8201-928544 BTP-M300.02.03R
Front cover
1
8201-928585 BTP-M300.02.03R
9.
8104-904626 BTP-M300.01.07.01R Tear-off bar 1 Black
10.
8303-900500 BTP-M270.01.07R Foot 4
11.
8201- 928547 BTP-M300.02.06R
Cover plate of power 1
Black
8201-928588 BTP-M300.02.06R White
12.
8201-909981 BTP-98NP.05.02R
Baffle of power switch
1 Black
8201-909987 BTP-98NP.05.02R 1 White
13.
8201- 928548 BTP-M300.02.07R Button 1
14.
8205-928534 BTP-M300-BS-01R Button label (English)
15.
8201- 904658 BTP-M300.01.05.05R
Baffle of middle cover
1 Black
8201-904663 BTP-M300.01.05.05R 1 White
16.
4002- 900901 ST2.6*10 Pan head self-tapping screw 2
17.
8299- 904671 BTP-M300.01.01.17R Ribbon guide plate 1
18.
3004-904961 Print head 1
19.
8099-904692 BTP-M300.01.01.09.03R Dustproof woolen washer 2
20.
8211-900651 BTP-M270.01.06.14R Left position bushing 2
21.
8299-904678 BTP-M300.01.01.16R Carriage 1
22.
8104-904609 BTP-M300.01.01.09.01R Carriage elastic plate 1
23.
8299-904676 BTP-M300.01.01.14R Eccentricity bushing 2
24.
8103-907686 BTP-M300.01.01.10.01R Carriage supporting plate 1
25.
7700-907762 BTP-M300.01.01.02R
Mechanism left plate (rustproof iron)
module
1
26.
4002- 900913 ST2.9×6 Pan head self-tapping screw 6
27.
8005- 902358 BK-S216.01.04.19R Hook spring 1
28.
3200- 901678 Carriage motor 1
29.
4930- 901147 96 MXL 019 Timing tooth belt 1
30.
4400- 900292 Φ3.5 “E”-ring 7
31.
8203- 900488 BTP-M270.01.03.18.04R Tight gear 1
