SNBC BTP-M300 - Main Control Board and Interfaces; Printer Overview and Control Board Diagram

BTP-M300 Service Manual
- 2 -
2 Printer Overview
The BTP-M300 printer consists of the following parts:
Pinter mechanism part, NDLF main control board, expanded interface board.
Main control board unit block diagram is shown as below:
FLASH
Communication interface
module
Communication
interface module
Main Control Board Unit Block Diagram
