1 Features and Specifications
1.1 Features
The BTP-M300 is a 9-pin serial impact dot matrix receipt printer offering high quality, high speed, and
stable performance. It is widely used in real-time printing on-site, such as POS system, kitchen and finance
applications.
The BTP-M300 can be connected with other devices via USB, parallel, serial and Ethernet interface, and it
provides drivers and applications under 2000/2003/XP/Vista.
1.2 Technical Specifications
Item Specification
Print mode 9-pin serial impact dot matrix
Print speed Max. 4.7LPS (400 dots/line)
Print width Max. 400(half dots)/200(full dots)
Paper
Paper type Continuous paper or marked paper
Single layer
Paper width: 80±0.5mm,76±0.5mm,69.5±0.5mm,57.5±0.5mm;
Paper thickness: 0.06—0.085mm
Multi-layer paper
(1 original+1 copies)
Paper width: 80±0.5mm,76±0.5mm,69.5±0.5mm,57.5±0.5mm;
Paper thickness: 0.05—0.08mm, total thickness≤0.14 mm
Character
Character type Font A: 9×9 Font B: 7×9 Chinese: 16×16
Characters/line (Default)
76mm 69.5mm 57.5mm
Font A 33 CPL 30 CPL 25 CPL
Font B 40 CPL 36 CPL 30 CPL
Chinese 22 CPL 20 CPL 16 CPL
Character size (Default) Font A: 1.6×3.1mm Font B: 1.2×3.1mm Chinese: 2.7×2.9mm
Characters/inch (Default) Font A: 13.3CPI Font B: 16CPI Chinese: 8.9CPI
Data
buffer
Receiving buffer 64KB/8KB/40Byte
NV image data 128KB
NV user data 8KB
Ribbon specification ERC-38 ribbon cartridge
Ribbon lifetime
ERC-38(P) 4,000,000 characters
ERC-38(B) 3,000,000 characters
ERC-38(B/R)
Black: 1,500,000 characters
Red: 750,000 characters
Communication interface USB / IEEE1284/RS-232/Ethernet /(optional)
Cash drawer connector
Can control 1～2 cash drawers
Power supply AC100-240V~1.0A Max 50-60Hz
Reliability
Printing Mechanism 10,000,000 lines
Print head 150,000,000 characters
Cutter 800,000 cuts(paper thickness:0.080mm, standard testing condition)
Operating temperature and humidity 5～45℃,20～90%RH (40 )℃
Storage temperature and humidity
-40～60℃,20%～93%RH (40 )℃
Dimensions 160(W)×245(D)×154(H)
Weight 3.0kg
