BTP-M300 Service Manual
- 51 -
32.
7700-907766 BTP-M300.01.01.08R
Fasten plate(rustproof iron) riveted
module
1
33.
7700-907764 BTP-M300.01.01.06R
Ribbon drive plate (rustproof iron)
riveted module
3
34.
7600-905463 HP sensor 1
35.
4000- 900297 M3×8 Screw module 6
36.
8203-901159 BSC-2000A.01.24R Scan gear 1 1
37.
8203-900490 BTP-M270.01.03.18.07R Ribbon driving gear 1
38.
8203-901158 BX-7R Gear 3 2
39.
8203-900487 BTP-M270.01.03.18.02R Driving gear 1
40.
8203-900489 BTP-M270.01.03.18.05R Transition gear 1
41.
4400-900294 Φ2 “E”-ring 2
42.
8299-904670 BTP-M300.01.01.15R Gear dustproof cover 1
43.
7700-928550 BTP-M300.01.05R Riveted mechanism right plate 1
44.
8001-904643 BTP-M300.01.01.20R Guide shaft 1
45.
8299-904674 BTP-M300.01.01.12R Plastic block 1
46.
7700-907765 BTP-M300.01.01.07R
Ribbon supporting plate (rustproof
iron) riveted module
1
47.
6101-901146 Ribbon 1
48.
8299- 904675 BTP-M280.01.01.13R Impact block 1
49.
4006-900295 M3×5 Spherical head screw 2
50.
Cutter stationary blade 1
51.
8299-909193 BTP-M300.01.09.11R Bolster plate of stationary blade 1
52.
4002-900913 ST2.9x6 Pan head self-tapping screw 40
53.
7700- 928650 BTP-M300.01.09.17R Fixing plate of stationary blade 1
54.
8103- 907682 BTP-M300.01.01.05.01R
Left supporting plate of stationary
blade
1
55.
4000-900185 M2.5x4 Pan head screw 1
56.
8104-909190 BTP-M300.01.09.08R Holder of paper press wheel 1
57.
8299- 909192 BTP-M300.01.09.10R
paper press wheel(paper-pulling
structure)
1
58.
8001-909232 BTP-M300.01.09.14R
Supporting shaft of paper press
wheel
1
59.
4400-900294 Φ2mm “E”-ring 1
60.
8103- 907681 BTP-M300.01.01.04.01R
Right supporting plate of stationary
blade
1
61.
Cutter sliding blade 1
62.
8103-909183 BTP-M300.01.09.01R
Fixing plate of sliding blade (without
retraction)
3
63.
8103-909185 BTP-M300.01.09.03R Platen roll rotation frame 1
64.
8299-909194 BTP-M300.01.09.12R Front plate of path
65.
907691 BTP-M300.01.02.04.01R Hook 1
66.
8005-904685 BTP-M300.01.02.08R Tension spring of hook 2
67.
8203-900993 BT-T080.01.11R Gear 25 1
