14
Model: Snorkel SR9244 SR1054
Part Number: 159-0037-000
Snorkel International, LLC
2009 Roseport Road
Elwood, KS 66024
IDENTIFICATION PLATE 1.6.2
The identification data of the machine is stated together with
“CE” marking on the plate fixed with rivets inside the driver
cabin indicated in the figure.
The frame number is marked on both the “CE” plate
and on the frame itself, at the point indicated in the figure.
The main data of the Diesel engine and its serial number
are marked on the plate located on the point indicated in
the figure.
The plates of all main components not manufactured and/or produced by Snorkel (e.g. pumps, axles, etc.)
are directly applied on the components themselves, at the points where the respective manufacturers have
originally placed them.
