ENGINE ERRORS 5.34
The list of main engine errors that can be encountered is below (code - description).
If the engine error screen appears (see chapter 3.1.2.11), contact Snorkel service.
SPN
FMI
Blinkcode
Error Identification
523912 2 Burner dosing valve (DV2) downstream pressure sensor; plausibility error
523912 0
Physical range check high for burner dosing valve (DV2) downstream pressure; shut
off regeneration
523912 1
Physical range check low for burner dosing valve (DV2) downstream pressure; shut
off regeneration. When burner injec
tor is actuated, the measured pressure does not
rise above ca. 1250mbar abs (expected: ca. 2400mbar).
523912 3
Sensor error burner dosing valve (DV2) downstream pressure sensor; signal range
check high
523912 4
Sensor error burner dosing valve (DV2) downstream pressure sensor; signal range
check low
102 2 Charged air pressure; system reaction initiated
102 2 Charged air pressure; system reaction initiated
523929 0
Fuel Balance Control integrator injector 1 (in firing order); maximum value
exceeded
523930 0
Fuel Balance Control integrator injector 2 (in firing order); maximum value
exceeded
523931 0
Fuel Balance Control integrator injector 3 (in firing order); maximum value
exceeded
523932 0
Fuel Balance Control integrator injector 4 (in firing order); maximum value
exceeded
523933 0
Fuel Balance Control integrator injector 5 (in firing order); maximum value
exceeded
523934 0
Fuel Balance Control integrator injector 6 (in firing order); maximum value
exceeded
523929 1 Fuel Balance Control integrator injector 1 (in firing order); minimum value exceeded
523930 1 Fuel Balance Control integrator injector 2 (in firing order); minimum value exceeded
523931 1 Fuel Balance Control integrator injector 3 (in firing order); minimum value exceeded
523932 1 Fuel Balance Control integrator injector 4 (in firing order); minimum value exceeded
523933 1 Fuel Balance Control integrator injector 5 (in firing order); minimum value exceeded
523934 1 Fuel Balance Control integrator injector 6 (in firing order); minimum value exceeded
523938 9
Timeout Error (BAM to packet) for CAN-Receive-Frame AT1IGCVol1 information;
factors & Sensorcalibration for NOX Sensor (SCR-system upstream cat; DPF- system
downstream cat)
523939 9
Timeout Error (BAM to BAM) for CAN-Receive-Frame AT1IGCVol1 information;
factors & Sensorcalibration for NOX Sensor (SCR-system upstream cat; DPF- system
downstream cat)

Snorkel SR9244 Specifications

General

Power Source	Diesel
Fuel Type	Diesel
Max Working Height	24.4 m
Max Platform Height	21.9 m
Platform Capacity	227 kg
Horizontal Reach	12.2 m
Weight	10, 660 kg
Overall Width	2.5 m
Overall Length	7.9 m
Stowed Height	2.9 m
Engine Power	55 kW
Drive Speed	4.8 km/h
