25
Model: Snorkel SR9244 SR1054
Part Number: 159-0037-000
Snorkel International, LLC
2009 Roseport Road
Elwood, KS 66024
LIMITS OF USE 2.3
The machine is designed and built to work in temperatures ranging between -20°C and
+40°C.
The machine is not designed to be used for forestry (the cabin is not tested against the risk of penetration of
objects, such as tree branches).
The machine is not designed to be used with crop sprayers that may be carried and/or towed (the cabin is
not built with sufficient insulation against toxic substances).
It is forbidden to use the machine with the boom extended and/or raised in case of
wind with intensity greater than 12.5 m/s (45 km/h), which corresponds to grade 6 on
the BEAUFORT scale. Grade 6 on the BEAUFORT scale indicates a wind that causes
continuous motion of large branches, which howls along telephone cables and makes
it difficult to use umbrellas.
With the machine stopped (0 km/h and parking brake engaged), it is possible to lift the load on a surface
tilted by±1° in a longitudinal and crosswise direction.
Loads can be handled with a fully retracted boom, lowered at a maximum speed of 0,4 m/s (at a walking
pace) and on a surface tilted by 14° if the load being handled is positioned upstream, by 10° if the load being
handled is positioned downstream or by ±5° if the load is tilted sideways.
The manoeuvres, even those without load, not related to load stacking or pick-up operations, must be
performed with the boom fully retracted or lowered
