85
Model: Snorkel SR9244 SR1054
Part Number: 159-0037-000
Snorkel International, LLC
2009 Roseport Road
Elwood, KS 66024
TOP RIGHT SIDE DASHBOARD 3.4
A third dashboard is found on the right side of the operator, at the top. A picture is provided below.
The following are found inside the dashboard:
1. Emergency lights – button with integrated light to activate/deactivate all four direction indicators.
Also the switch warning light blinks when the device is running.
2. Work lights - button with integrated light to activate/deactivate the work lights on the cabin.
3. Front windscreen wiper - button with integrated light to activate/deactivate the front
windscreen wiper. The button has 3 positions: position 0 = off, position 1 = low speed,
position 2 = high speed.
4. Flash beacon - button with integrated light to activate/deactivate the flash beacon.
5. Cabin light - press to the right to activate it and to the left to deactivate it.
6. Radio set up.
