75
Model: Snorkel SR9244 SR1054
Part Number: 159-0037-000
Snorkel International, LLC
2009 Roseport Road
Elwood, KS 66024
3.2.1.18
CONSTANT FLOW
The "constant flow" function is optional and is suitable for specific applications requiring a constant oil flow
for the hydraulic services at the head of the telescopic boom. It can be adjusted by buttons 1 and 2 on the
display or the roller 2 joystick (see joystick paragraph); it is activated with the button 14 on the right-side
dashboard.
Press the UP or DOWN buttons (on-board computer) or roller 2 (joystick) to adjust the flow.
Press the OK button (on-board computer) to go back to the “main” page.
Press the MENU button (on-board computer) to go back to the “menu” page.
Press button 14 (right dashboard) for 3 seconds to activate the function (the symbol switches from
to ) This function can only be activated with the engine running.
Press button 14 the right dashboard to deactivate the function.
