Inflation can pose some risk and it is best to use a gun fitted with an extension pipe so as to be positioned
at a safe distance and protected from a possible explosion.
To replace the tires, refer to the “tires” paragraph in the “general information, chap.1” section.
To adjust the inflation pressure, refer to the following table and the tire installed on the machine:
TIRE MODEL AND DIMENSIONS
BRAND
PRESSURE [bar]
LOAD INDEX
405/70-20 MPT-01 TL 14PR MITAS 3.5 149B
405/70-20 MPT800 14PR CEAT 3.5 149B
405/70-20 4L R1 CAMSO 5.5 158 A8
405/70-24 MPT-01 TL 14PR MITAS 4.0 152B
405/70-24 MPT-04 TL 14PR MITAS 4.0 151D
405/70-24 MPT800 14PR CEAT 4.0 152B
405/70-24 4L R1 CAMSO 5.2 169 A2
445/65 R22.5 AGP23 AEOLUS 7.5 169F
