4.1.4. Electrical readings
DIRIS Digiware
D-40 D-50 D-70 C-31
Function
Centralisation of measurement points • • • •
High-resolution LCD display (conguration, selection and visualisation
of multiple circuits)
• • •
Power supply
24VDC • • • •
Communication
Slave RS485 modbus • •
Master RS485 modbus • •
Digiware bus • • • •
Ethernet Modbus TCP • •
BACnet IP Ethernet •
SNMP Ethernet v1, v2, v3 •
Webview embedded web server •
Format
Width/Number of modules 97x97mm 97x97mm 97x97mm 18mm / 1
Part number 4829 0199 4829 0201 4829 0202 4829 0101
DIRIS Digiware U
U-31dc U-32dc
Measured voltages
Nominal voltages 24VDC - 48VDC 60VDC - 150VDC
Admissible min/max voltages 19.2VDC - 60VDC 48VDC - 180VDC
Multi-measurement
Vdc •
Quality analysis*
Vripple (Voltage ripple) •
Vrms •
Alarms
In the event of overloads •
History of average values
•
Format
Width/Number of modules 18mm / 1
Part number 4829 0150 4829 0151
* Vrms
2
= Vdc
2
+ Vripple
2
