socomec DIRIS Digiware C-31 Installation

22 EN
DIRIS DIGIWARE DC - 545830B - SOCOMEC
6.2. DIRIS Digiware connection with voltage adapter
U32dc: min. 48- max.180VDC
4 positions
screw connection 0.25Nm max.
solid 0.2mm
2
-> 2.5mm
2
stranded 0.2mm
2
-> 2.5mm
2
7 mm
Only use a SOCOMEC Digiware bus cable (UTP RJ45 straight, twisted pair, unshielded, AWG24, 600VCat 5 -10 /
+70°C).
When wiring, make sure you separate the low voltage (LV) section and the safety extra low voltage (SELV) section to
prevent any risk of electric shock.
DIRIS
Digiware
C-31
Supply
&
Com
DIRIS
Digiware
U-3xdc
DC Voltage
inputs (U
Adapter
RS485 line polarisation
OFF = RS485 line polarisation disabled
(by default)
ON = RS485 line polarisation enabled
SELV: Safety Extra Low Voltage
(1)
Micro USB - type B
(2)
Earth must not be used in a neutral system not connected to earth
(3)
Adapter: U500dc, U1000dc or U1500dc
24 V
SUPPLY
RS485
NC
1 2
ON
D
i
g
i
w
a
r
e
B
u
s
Display
DIRIS Digiware D
Power supply
24VDC SELV
2 positions - screw connection,
0.25 Nm max.
solid 0.2mm
2
-> 2.5mm
2
stranded 0.2mm
2
-> 2.5mm
2
7 mm
Communication
RS485 Modbus SELV
3 positions - screw connection,
0.25 Nm max.
solid 0.14mm
2
-> 1.5mm
2
stranded 0.14mm
2
-> 1.5mm
2
7 mm
or
2 positions
screw connection
0.25Nm max.
solid 0.2mm
2
-> 2.5mm
2
stranded 0.2mm
2
-> 2.5mm
2
7 mm
Adapter (3)
4 positions
screw connection
0.25Nm max.
solid 0.2mm
2
-> 2.5mm
2
stranded 0.2mm
2
-> 2.5mm
2
7 mm
NC NC - +
+
+
- (0 V)
-
- NC NC +
- +
(2)
651.3
v
