DIRIS DIGIWARE DC - 545830B - SOCOMEC
I-3xdc
3x current sensor
inputs
Digiware Bus
Termination
(1)
IO-10
4x digital inputs
12VDC-3mA max.
5 screw connections,
0.25Nm max.
2x digital outputs
48VDC-50mA max.
4 screw connections,
0.25 Nm max.
IO-20
2x analogue inputs
0/4-20mA
4 screw connections,
0.25Nm max.
solid 0.14mm
2
-> 1.5mm
2
stranded 0.14mm
2
->
1.5mm
2
7 mm
DIRIS
DigiwareIO
Inputs /
Outputs
DIRIS
Digiware
I
-3xdc
DC Current
inputs (3I)
(1)
OUT
IN
