socomec DIRIS Digiware C-31 Installation

20 EN
DIRIS DIGIWARE DC - 545830B - SOCOMEC
6. CONNECTION
6.1. DIRIS Digiware connection without voltage adapter
Display
DIRIS Digiware D
SELV: Safety Extra Low Voltage
(1)
Micro USB - type B
(2)
Earth must not be used in a neutral system not connected to earth
RS485 line polarisation
OFF = RS485 line polarisation disabled
(by default)
ON = RS485 line polarisation enabled
24 V
SUPPLY
RS485
NC
1 2
ON
DIRIS
Digiware
U-3xdc
DC Voltage
inputs (U)
- + NC NC
NC NC - +
DIRIS
Digiware
C-31
Supply
&
Com
D
i
g
i
w
a
r
e
B
u
s
Power supply
24VDC SELV
2 positions - screw connection, 0.25 Nm max.
solid 0.2mm
2
-> 2.5mm
2
stranded 0.2mm
2
-> 2.5mm
2
7 mm
Communication
RS485 Modbus SELV
3 positions - screw connection, 0.25 Nm max.
solid 0.14mm
2
-> 1.5mm
2
stranded 0.14mm
2
-> 1.5mm
2
7 mm
or
(2)
(1)
Voltage input U
U31dc: min. 19.2-max. 60VDC
4 positions
screw connection 0.25Nm max.
solid 0.2mm
2
-> 2.5mm
2
stranded 0.2mm
2
-> 2.5mm
2
7 mm
or
U32dc: min. 48- max. 180VDC
4 positions
screw connection 0.25Nm max.
solid 0.2mm
2
-> 2.5mm
2
stranded 0.2mm
2
-> 2.5mm
2
7 mm
- (0 V)
- (0 V)
+
+
- Only use a SOCOMEC Digiware bus cable (UTP RJ45 straight, twisted pair, unshielded, AWG24, 600VCat 5, -10 /
+70°C).
- When wiring, make sure you separate the low voltage (LV) section and the safety extra low voltage (SELV) section to
prevent any risk of electric shock.
