Re-screw the cable glands to the connector housing.
Figure. 5-12 Connecting PV(d)
6. Insert the positive and negative connectors into the
corresponding DC input terminals of the inverter until you
hear a “clicking” sound.
Figure. 5-13 Connecting PV(e)
①
Locking
NOTE
 Insert the protective caps into the unused DC
connections.
