HYD 5/6/8/10/15/20KTL-3PH USER MANUAL
57
Smart Meter Configuration
The smart meter is preconfigured to be used with the inverter
with these settings:
Modbus Address: 1
Baud Rate: 9600
Current Ratio: 40:1
In case you want to change or check the settings, please refer to
below procedure:
Modbus Address and Baud Rate setting
Figure. 5-24 Meter address and baud rate setting
NOTE
 The arrows on the current transformers direct to the
grid.
 Up to 200 A measurement
 Accuracy class and load rating(VA/Ω):1 class
 Rated operating voltage:AC 0.66KV(Equivalent to 0.69KV
GB156-2003)
 Rated frequency: 50-60Hz
 Ambient temperature: -40℃~85℃
 Altitude:≤3000m
