SolaX Power X1-Hybrid G4 Series - 2.4 Dimensions & Terminals

28
29
InstallationInstallation
d)
Self-tapping
screws
Outer hexagon wrench
(Torque :2.5±0.2 N·m)
Gasket
c)
b)
Expansion bolts
Step 2: hang the inverter on the bracket.
Ø
c) Insert expansion bolt into the hole, use rubber hammer to knock the
expansion screw bolt into the wall;
d) The bracket is aligned with the screw uses the inner hexagonal wrench to
screw the tapping screw until the expansion bolt "bang" is heard.
8
0.
00 m
m
Φ10 Drill
(Depth :80 mm)
Rubber hammer
4.6 Mounting
Preparation
Step 1: Fix the wall bracket to the wall.
Ø
Ø
Please prepare the following tools before installation.
Installation tools: screwdriver, wrench ,Φ10 drill, hammer, socket wrench set
and Hexagon keys.
First find the expansion screw and the wall bracket in the accessory bag,
as shown below:
a)
Expansion bolts, Gasket,Tapping screws
Bracket
a)Use a marker to mark drilling holes of the bracket on the wall .Drill
holes at marked spots with depth of 80mm.
