SolaX Power X1-Hybrid G4 Series User Manual

66
67
Firmware Upgrading
2) Please contact our service support through service@solaxpower.com to
obtain the firmware, and store the firmware in the U disk according to the
following path.
Upgrade steps
Update:
For ARM le:“update \ARM\618.00361.00_Hybrid_X1G4_ARM_V1.01.0710.usb”;
For DSP le:“update\DSP\618.00360.00_Hybrid_X1G4_DSP_V1.01.0710.hex”;
Long press for 5
seconds
Step 1. Please save the "Upgrade" firmware in your U disk first, and press
the "Enter" button on the inverter screen for 5 seconds to enter the OFF
mode.
Step 2. Find the "update" port of the inverter, use a flat-blade screwdriver
or coin with the same width to remove the waterproof cover, and insert
the U disk.
Waterproof cover
Flat-blade screwdriver or coin
(Port size: 12·2mm;
Torque: 1.5±0.2N·M)
Ø
Step 3. LCD operation, enter the upgrade interface "update", as shown
below(a): Please press the up and down keys to select ARM, then press
down to set "OK", press the enter key to enter the
software version interface ;
Step 4. Please confirm the new firmware version again and select the
firmware to upgrade. The upgrade takes about 20 seconds.
(d) When it is completed, the LCD screen returns to the "Update" page.
Upgrade(ARM)
Cancel
>OK
Upgrade Selection
>ARM
DSP
Update(ARM) Update
Update(ARM)
>618.00361.00_Hybrid_
X1G4_ARM_V1.01
0710.usb
(a) (b)
(c)
>ARM
DSP
(e)
Upgrading---------25%
(d)
U Disk
Firmware Upgrading
