NGL E
Step 2. Plug the Pocket WiFi Plus into the DONGLE port, use the screws
in step 1 to tighten it.
DON GLE
Phillips screwdriver
Torque: 1.2±0.1N·m
62
63
Electrical Connection
Ø
After the inverter is checked, the condnct the following
steps:
Turn on the Load switch and Off-grid switch.
Turn on the battery switch.
Ensure that the external Off-grid contactor is well connected. (If applicable)
Make sure the battery is well connected.
Make sure the CT is connected.
Confirm that all DC lines and AC lines are connected.
Make sure that the inverter is fixed on the wall.
Long press the “Enter “key for 5 seconds to exit the Off mode.
(The mode is factory defaulted as Off Mode)
8
Ensure that all ground wires are grounded.
5.8 Check All Below Steps Before Starting Inverter
Electrical Connection
N
BAT
Battery
N-BAR for loads
N-BAR for off-grid loads
off-grid loads
Loads
X1-Hybrid G4
PV 1
PV 2
E-BAR
RCD
Breaker
Grid
Breaker
Grid
Off-grid
Main Breaker
Breaker
Breaker
CT
CT
Breaker
PE
RCD
8
To Next Page
