7.2 Screen Menu Structure
The main inter face is the default inter face, the inver ter will
automatically return to this interface when the system started up
successfully or not operated for a period of time.
The information of the interface is as below. “Power” means the
instant output power; “ Today” means the power generated within
the day. “Battery” means the left capacity of battery energy.
Power 0W
Today 0.0KWh
Battery
80%
Normal
The menu interface is another interface for users to change settings
or obtain information.
-When the LCD displays the main interface, click "OK" to enter this
interface.
-The user can select up and down the menu, and press the "OK" key
to conrm.
System ON/OFF
Work Mode
System Status
Menu
Ø
7.3 LCD Operation
70
71
＞
Setting
Setting
Note:" "This part of the content cannot be set by the end user.
Please contact the installer or SolaX if necessary.
Menu interface
ON/OFF
System
System Status
PV1
PV2
Battery
On-grid
Off-grid
Meter/CT
Off-grid
Meter/CT-1
Meter/CT-2
On-grid
Error Logs
1
Forced charge
Forced discharge
Stopcharge&discharge
Work Mode
Self Use
Backup mode
Feed-in priority
Manual
2
3
History Data
4
About
Inverter
Battery
Internal Code
6
settings
5
Date&Time
Language
Off grid mode -
Self-use mode
Backup mode
Chrg & dischrg period
Feed-in Priority
User Password
User settings
Safety Code
Meter/CT Settings
Grid Parameters
Self Test
LVRT Function
Shadow Fix
X1-Matebox Setting
Pu Function
Modbus
Export Control
Power Factor
Advance Password
DRM Function
Reset
Power limit
Main Breaker Limit
Advanced settings
Safety Mode
DIO Function
COM Port Select
Manufactory settings
To Next Page
