26
27
InstallationInstallation
≥300mm
≥300mm
≥300mm≥300mm
300mm
300mm
300mm
300mm
300mm
Position
Min Distance
Left
Right
Up
Down
Forward
Reserved space dimensions of
installation
4.5.3 Installation Space Requirements
Reserve enough space when installing inverter (at least 300mm) for heat
dissipation.
The distance of installation space for multiple inverters is as follows:
≥300mm
≥300mm ≥300mm
≥300mm
≥300mm
≥300mm
≥300mm
≥300mm
≥300mm
≥300mm
≥300mm
≥300mm
4.5 Installation Site Conditions
4.5.1 Installation Carrier Requirements
Do not install the inverter near flammable materials.
Please install the inverter on a solid object that can withstand the weight
requirements of the inverter and energy storage system.
Please be careful not to install the inverter in the plasterboard wall or
similar to the residential places with poor sound insulation ,so as not to
work with noise and interfere with the residents' life in the morning.
4.5.2 Installation Requirements
Install the inverter at a maximum back tilt of 5 degrees, the inverter can
not be tilted forward, inverted, excessive back tilted or side tilted.
≤5°
