34 35
Electrical Connections
Electrical Connections
X1-Hybrid G4 series inverter are single-phase inverter inverter. Suitable for
rated voltage 220/230/240V, frequency 50/60Hz. For more technical
requirments,please consult the requirements of the local public grid.
The circuit breaker should be installed between the inverter and the mains,
and the load should not be directly connected to the inverter.
Grid Cable and Micro-breaker recommended
Figure: Wrong connection of load and inverter
Cable (copper)
Micro-Breaker
Model
X1-Hybrid-3.0-D
X1-Hybrid-3.0-M
X1-Hybrid-3.7-D X1-Hybrid-5.0-D X1-Hybrid-6.0-D
4-6mm² 6-8mm²
4-6mm²
4-6mm²
50A
Grid port connection
Ø
Off-grid Cable and Micro-breaker recommended
Cable (copper)
Micro-Breaker
Model
X1-Hybrid-3.0-D
X1-Hybrid-3.0-M
X1-Hybrid-3.7-D
X1-Hybrid-3.7-M
X1-Hybrid-5.0-D
X1-Hybrid-5.0-M
X1-Hybrid-6.0-D
X1-Hybrid-6.0-M
3-4mm²
3-4mm²
8-10mm² 8-10mm²
25A 25A 32A 32A
50A40A32A
X1-Hybrid-7.5-D
6-8mm²
50A
X1-Hybrid-7.5-D
X1-Hybrid-7.5-M
8-10mm²
40A
5.2 Grid Port and Off-grid Output Connection
X1-Hybrid-3.0-M
X1-Hybrid-3.7-M
X1-Hybrid-5.0-M
X1-Hybrid-6.0-M
X1-Hybrid-7.5-M
4-6mm²
4-6mm²
Cable (copper)
Micro-Breaker
3-4mm²
3-4mm²
25A 25A 32A 32A
6-8mm²
40A
Model
PV1+
PV2+
PV1-
PV2-
The following is the location of the inverter's positive and negative
(PV-/PV+) ports.
Schematic diagram of the inverter PV connected.
