SolaX Power X3-Hybrid Series User Manual

4.5 Installation Site Conditions
4.5.1 Installation Carrier Requirements
4.5.2 Installation Requirements
Install the inverter at a maximum back tilt of 5 degrees, the inverter can
not be tilted forward, inverted, excessive back tilted or side tilted.
Type
Tool equipment
Name
Name
Safety
gloves
Safety
shoes
Individual
Protection
Tool
InstallationInstallation
26
27
Type
Equipment
Preparation
Name
Requirement
Cable
Preparation
Breaker
PV end
wire
EPS
(Off-grid)
end wire
Grid end
wire
Communi-
cation lines
PE Cable
Dedicated PV wire, line number
#4 mm² withstand voltage 1000V,
temperature resistance 105℃ fire
resistance grade VW-1
Battery
Cable
Five-core cable
Five-core cable
Grid port and EPS(Off-grid) port wiring
section (4.5.2)
Twisted pair with shield
Conventional wire
Conventional wire
≤5°
Do not install the inverter near flammable materials.
Please install the inverter on a solid object that can withstand the
weight requirements of the inverter and energy storage system.
Please be careful not to install the inverter in the plasterboard wall
or similar to the residential places with poor sound insulation, so as
not to work with noise and interfere with the residents' life in the
morning.

SolaX Power X3-Hybrid Series Specifications

General

Number of MPP Trackers	2
Model	X3-Hybrid Series
Phase	Three Phase
Communication Interfaces	RS485
Battery Compatibility	Lithium-Ion
Grid Frequency	50Hz / 60Hz
Operating Temperature	-25 ~ +60 °C
