SolaX Power X3-Hybrid Series User Manual

Change History
Changes between document versions are cumulative. The latest version contains
all updates made in previous versions.
Version 02 (Dec. 14, 2022)
Update the inverter power (Added 10.0K-D for the certication of Belgium)
Update 2.3 Work Modes (Separated the description of the forced charging
period and allowed discharging period)
Update 2.2 Electrical Block Diagram of the System (Changed the place of
RCD in the D and M version diagram in Australia)
Update 5.5.3 Parallel Connection (Added a note about “External ATS” setting
and corrected the port of the inverter the meter connected to)
Update 7.3 LCD Operation (Changed the “External ATS” setting)
Update 3 Technical Data (Revised the description of some data and added
some new parameters.)
Update 1.3.2 Explanation of Symbols (Deleted the icon and description of
“UNKI”)
Update 5.5.4 COM Communication (A computer is connected to an inverter
through a USB-RS485 converter.)
Version 03 (May. 08, 2023)
Update 2.3 Work Modes and 7.3 LCD Operation (Added peak shaving mode
under work modes chapter.)
Update 7.3 LCD Operation (Updated the LCD display under most settings.)
Update 3 Technical Data (Changed the data of Max. input current to 28/16 A;
and the data of Max. short circuit current to 35/20 A for 8kW+ inverters.)
Update 4.2 Packing List (Deleted the “PE cable” in the packing list of the M
version inverter.)
Update 5.1 PV Connection (Deleted the COMM PV module connection
method.)
Update 5.5.3 Parallel Connection (Updated the description.)

SolaX Power X3-Hybrid Series Specifications

General

Number of MPP Trackers	2
Model	X3-Hybrid Series
Phase	Three Phase
Communication Interfaces	RS485
Battery Compatibility	Lithium-Ion
Grid Frequency	50Hz / 60Hz
Operating Temperature	-25 ~ +60 °C
