29 • Control Keypad
___________________________________________________________________________________________
Displays in MINIMIZED MODE and MAXIMIZED MODE
(Refer below for changing modes)
Display and default
values
Becomes operational only after Start signal.
When voltage drops to zero (voltage outage) the
starter will trip immediately, overriding the delay.
Trips the starter when mains voltage increases
above the set level for a time longer than
OVEERVOLT DELAY.
For operation convenience, there are two display
modes:
MINIMIZED – Display of pre-selected
parameters for standard applications.
MAXIMIZED – Display of all possible
parameters.
Setting Display Mode to MINIMIZED will
minimize the LCD displays. (Refer to section
7.4 7.6 on page 21 for more details)
PARAMETERS LOCK
NOT LOCKED
unlocks
parameter
modifications.
The software lock prevents undesired parameter
modification.
When locked, upon pressing Store , ▼ or▲
keys, the LCD displays:
STORE ENABLE
MAIN PARAMETERS
To store selected parameters, press Store key.
Note: Storing selected parameters is possible
only when RAMP LED does not lit.
Storing cannot be done when Soft Starting or
Soft Stopping.
When parameters have been correctly stored,
the LCD will read:
This concludes MAIN PARAMETER settings.
Pressing Select key after “DATA SAVED OK”
returns to the first display in this mode.
Note:
In case of a failure in parameter storing, the LCD
In this case Refer to section 9 – “TROUBLE
To Next Page
