Measurement of differential leakage current
Note: In the half-time of the measurement, the tester automatically changes the polarity of the test
socket and as a final result it displays the value of higher leakage current.
Display range
Resolution
Measurement uncertainty
(basic)
0,00 mA...3,99 mA
0,01 mA
 (5 % m.v. + 2 digits)
4,0 mA...19,9 mA
0,1 mA
Influencing factor
Designa-
tion
Additional uncertainty
Position
E
1
0 %
Supply voltage
E
2
0 %
Temperature
E
3
0,1 %/ºC
Power consumption of
the tested unit
E
4
Current
common
Additional
uncertainty
0 A...4 A
0
4 A...8 A
±0,03 mA
8 A...16 A
±0,08 mA
Low frequency magnetic
field
E
5
2 digits I < 4 mA
0 digits for I ≥ 4 mA
The shape of the net-
work voltage (CF)
E
8
0 %
 adjustable upper limit in the range of: 0,10 mA…19,9 mA with resolution of 0.01mA/0.1mA
 adjustable measuring time in the range of: 3…180s with resolution of 1 s
 when measuring devices whose power consumption exceeds 10A, the measurement time is
automatically limited to maximum of 15s.
Measurement of touch leakage current
Note: In the half-time of the measurement, the tester automatically changes the polarity of the test
socket and as a final result it displays the higher value.
Display range
Resolution
Measurement uncertainty
(basic)
0,001 mA...4,999 mA
0,001 mA
 (5 % m.v. + 3 digits)
Influencing factor
Designation
Additional uncertainty
Position
E
1
0 %
Supply voltage
E
2
0 %
Temperature
E
3
0,25 μA/ºC
The shape of the network
voltage (CF)
E
8
0 %
 the bandwidth of test current results from the measuring system with adjusted touch current
which simulates human perception and reaction, in accordance with EN 60990: 2002
 adjustable upper limit in the range of: 0,01 mA…4,99 mA with resolution 0,01mA
 adjustable measuring time in the range of: 3s…180s with resolution of 1 s
 when measuring devices whose power consumption exceeds 10A, the measurement time is
automatically limited to maximum of 15s.
