:: Technical Specifications
Inputs
AUDIO 2 Stereo audio inputs, RCA Connector, -8dbm, 47KΩ, front and rear
VIDEO 2 Composite video inputs, RCA Connector, 75Ω, 1Vp-p
RF Antenna or CATV Input, F-Connector, 75Ω
Outputs
AUDIO 1 Stereo audio output, RCA Connector, -8dbm, 1.5kΩ
AUDIO (DVD only) Digital audio output (coaxial), 1 stereo audio output
VIDEO 1 Composite video output, RCA Connector, 75Ω, 1Vp-p
VIDEO (DVD ONLY) 1 S-Video output, S-Connector, 75Ω, Y = 1.0Vp-p, C = 0.286Vp-p
1 Component video output, 75Ω, Y = 1.0Vp-p, Pb = 0.7Vp-p, Pr = 0.7Vp-p
VCR Specifications
RF Channel 3 or 4
VIDEO SYSTEM 1/2-inch VHS system, 4 rotary head helical scanning; FM azimuth luminance; chrominance: converted
sub system phase shift
AUDIO TRACK Normal: 1 track; Hi-Fi: 2 track
PLAY/RECORD TIME T-180 tape: SP 3 hours, SLP 9 hours
FF/REW TIME T-120 tape: <2 minutes
HEADS Video: DA 4 rotary
Audio: 2 rotary heads (Hi-Fi); 1 stationary head (Linear)
Control: 1 stationary head
TV shows blue screen. • If current channel is too weak to display clear picture, a blue screen is displayed.
• Double-check antenna connections or tuner settings.
Power button blinking. • Unit is in Auto Power Off mode. If you press POWER while rewinding, copying, Timer Recording or One-
Touch Recording, the unit will automatically turn off when that function is complete.
• Press POWER to toggle Auto Power on and off.
No stereo sound. • Connect TV and DVD+VCR with audio/video cables. If your TV and DVD+VCR are connected with an RF
coaxial cable, you will only hear stereo sound if the DVD+VCR is turned off.
