2.1.1.5 CHECKSUM CALCULATION
The last ROM address are reserved area. User should avoid these addresses (last address) when calculate the
Checksum value.
¾ Example: The demo program shows how to calculated Checksum from 00H to the end of user’s code.
MOV A,#END_USER_CODE$L
B0MOV END_ADDR1, A ; Save low end address to end_addr1
MOV A,#END_USER_CODE$M
B0MOV END_ADDR2, A ; Save middle end address to end_addr2
CLR Y ; Set Y to 00H
CLR Z ; Set Z to 00H
@@:
MOVC
B0BSET FC ; Clear C flag
ADD DATA1, A ; Add A to Data1
MOV A, R
ADC DATA2, A ; Add R to Data2
JMP END_CHECK ; Check if the YZ address = the end of code
AAA:
INCMS Z ; Z=Z+1
JMP @B ; If Z != 00H calculate to next address
JMP Y_ADD_1 ; If Z = 00H increase Y
END_CHECK:
MOV A, END_ADDR1
CMPRS A, Z ; Check if Z = low end address
JMP AAA ; If Not jump to checksum calculate
MOV A, END_ADDR2
CMPRS A, Y ; If Yes, check if Y = middle end address
JMP AAA ; If Not jump to checksum calculate
JMP CHECKSUM_END ; If Yes checksum calculated is done.
Y_ADD_1:
INCMS Y ; Increase Y
NOP
JMP @B ; Jump to checksum calculate
CHECKSUM_END:
…
…
END_USER_CODE: ; Label of program end
