SONIX SN8P2624 - 1.3 Pin Assignment

SN8P2624
8-Bit Micro-Controller
SONiX TECHNOLOGY CO., LTD Page 9 Version 0.3
1.3 PIN ASSIGNMENT
SN8P2624K (SK-DIP 28 pins)
SN8P2624S (SOP 28 pins)
SN8P2624X (SSOP 28 pins)
P0.1/INT1 1 U 28 RST/VPP/P0.2
VDD 2 27 XIN
P5.4 3 26 XOUT/Fcpu
VSS 4 25 P2.7
P0.0/INT0 5 24 P2.6
P5.0 6 23 P2.5
P5.1 7 22 P2.4
P5.2 8 21 P2.3
P5.3/BZ1/PWM1 9 20 P2.2
P1.0 10 19 P2.1
P1.1 11 18 P2.0
P1.2 12 17 P1.7
P1.3 13 16 P1.6
P1.4 14 15 P1.5
SN8P2624K
SN8P2624S
SN8P2624X
