TIMERS
8.1 WATCHDOG TIMER
The watchdog timer (WDT) is a binary up counter designed for monitoring program execution. If the program goes into
the unknown status by noise interference, WDT overflow signal raises and resets MCU. Watchdog clock controlled by
code option and the clock source is internal low-speed oscillator (16KHz @3V, 32KHz @5V).
Watchdog overflow time = 8192 / Internal Low-Speed oscillator (sec).
VDD Internal Low RC Freq. Watchdog Overflow Time
3V 16KHz 512ms
5V 32KHz 256ms
Note: If watchdog is “Always_On” mode, it keeps running event under power down mode or green
mode.
Watchdog clear is controlled by WDTR register. Moving 0x5A data into WDTR is to reset watchdog timer.
0CCH Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
WDTR
WDTR7 WDTR6 WDTR5 WDTR4 WDTR3 WDTR2 WDTR1 WDTR0
Read/Write W W W W W W W W
After reset 0 0 0 0 0 0 0 0
¾ Example: An operation of watchdog timer is as following. To clear the watchdog timer counter in the top
of the main routine of the program.
Main:
MOV A,#5AH ; Clear the watchdog timer.
B0MOV WDTR,A
…
CALL SUB1
CALL SUB2
…
…
…
JMP MAIN
