SONIX SN8P2624 - 11.1.3 Programming Pin Mapping

SN8P2624
8-Bit Micro-Controller
SONiX TECHNOLOGY CO., LTD Page 90 Version 0.3
11.1.3 PROGRAMMING PIN MAPPING
Programming Information of SN8P2600A Series
Chip Name SN8P2624
Writer V2.5
Connector
EZ Writer / Writer
V3.0
Connector
OTP IC / JP3 Pin Assigment
Number Name Numbe
r
Name Number Pin Number Pin
2 VDD 1 VDD 2 VDD
1 GND 2 GND 4 VSS
4 CLK 3 CLK 6 P5.0
3 CE 4 CE - -
6 PGM 5 PGM 10 P1.0
5 OE 6 OE 7 P5.1
8 D1 7 D1 - -
7 D0 8 D0 - -
10 D3 9 D3 - -
9 D2 10 D2 - -
12 D5 11 D5 - -
11 D4 12 D4 - -
14 D7 13 D7 - -
13 D6 14 D6 - -
16 VDD 15 VDD - -
15 VPP 16 VPP 28 RST
18 HLS 17 HLS - -
17 RST 18 RST - -
- - 19 - - -
- - 20 ALSB/PDB 11 P1.1
