6.8 T0 INTERRUPT OPERATION
When the T0C counter occurs overflow, the T0IRQ will be set to “1” however the T0IEN is enable or disable. If the
T0IEN = 1, the trigger event will make the T0IRQ to be “1” and the system enter interrupt vector. If the T0IEN = 0, the
trigger event will make the T0IRQ to be “1” but the system will not enter interrupt vector. Users need to care for the
operation under multi-interrupt situation.
¾ Example: T0 interrupt request setup.
B0BCLR FT0IEN ; Disable T0 interrupt service
B0BCLR FT0ENB ; Disable T0 timer
MOV A, #20H ;
B0MOV T0M, A ; Set T0 clock = Fcpu / 64
MOV A, #74H ; Set T0C initial value = 74H
B0MOV T0C, A ; Set T0 interval = 10 ms
B0BSET FT0IEN ; Enable T0 interrupt service
B0BCLR FT0IRQ ; Clear T0 interrupt request flag
B0BSET FT0ENB ; Enable T0 timer
B0BSET FGIE ; Enable GIE
¾ Example: T0 interrupt service routine.
ORG 8 ; Interrupt vector
JMP INT_SERVICE
INT_SERVICE:
… ; Push routine to save ACC and PFLAG to buffers.
B0BTS1 FT0IRQ ; Check T0IRQ
JMP EXIT_INT ; T0IRQ = 0, exit interrupt vector
B0BCLR FT0IRQ ; Reset T0IRQ
MOV A, #74H
B0MOV T0C, A ; Reset T0C.
… ; T0 interrupt service routine
…
EXIT_INT:
… ; Pop routine to load ACC and PFLAG from buffers.
RETI ; Exit interrupt vector
