ELECTRICAL CHARACTERISTIC
10.1 ABSOLUTE MAXIMUM RATING
Supply voltage (Vdd)…………………………………………………………………………………………………………………….……………… - 0.3V ~ 6.0V
Input in voltage (Vin)…………………………………………………………………………………………………………………….… Vss – 0.2V ~ Vdd + 0.2V
Operating ambient temperature (Topr)
SN8P2624K, SN8P2624S, SN8P2624X ………………………………………………………………………………………………….. 0
°C ~ + 70°C
SN8P2624KD, SN8P2624SD, SN8P2624XD ……………………………………………………………………………………………. –40
°C ~ + 85°C
Storage ambient temperature (Tstor) ………………………………………………………………….………………………………………… –30
°C ~ + 125°C
10.2 ELECTRICAL CHARACTERISTIC
(All of voltages refer to Vss, Vdd = 5.0V, fosc = 4MHz, ambient temperature is 25
°
C unless otherwise note.)
PARAMETER SYM. DESCRIPTION MIN. TYP. MAX. UNIT
Operating voltage Vdd Normal mode, Vpp = Vdd 2.4 5.0 5.5 V
RAM Data Retention voltage Vdr - 1.5* - V
Vdd rise rate Vpor Vdd rise rate to ensure power-on reset 0.05 - - V/ms
ViL1 All input ports Vss - 0.3Vdd V
Input Low Voltage
ViL2 Reset pin Vss - 0.2Vdd V
ViH1 All input ports 0.7Vdd - Vdd V
Input High Voltage
ViH2 Reset pin 0.9Vdd - Vdd V
Reset pin leakage current Ilekg Vin = Vdd - - 2 uA
Vin = Vss , Vdd = 3V 100 200 300
I/O port pull-up resistor Rup
Vin = Vss , Vdd = 5V 50 100 150
K
Ω
I/O port input leakage current Ilekg Pull-up resistor disable, Vin = Vdd - - 2 uA
I/O output source current IoH Vop = Vdd – 0.5V - 12* -
sink current IoL Vop = Vss + 0.5V - 15* -
mA
INTn trigger pulse width Tint0 INT0 interrupt request pulse width 2/fcpu - - cycle
Vdd= 5V, 4Mhz - 2.5 5 mA
Idd1
normal Mode
(No loading,
Fcpu = Fosc/4)
Vdd= 3V, 4Mhz - 1 2 mA
Vdd= 5V, 32Khz - 20 40 uA
Idd2
Slow Mode
(Internal low RC, stop
high clock)
Vdd= 3V, 16Khz - 5 10 uA
Vdd= 5V - 1 2 uA
Idd3 Sleep Mode
Vdd= 3V - 0.7 1.5 uA
Vdd= 5V, 4Mhz - 0.6 1.2 mA
Vdd= 3V, 4Mhz - 0.25 0.5 mA
Vdd=5V, ILRC 32Khz - 15 30 uA
Supply Current
Idd4
Green Mode
(No loading,
Fcpu = Fosc/4
Watchdog Disable)
Vdd=3V, ILRC 16Khz - 3 6 uA
LVD detect level V
LVD
Low voltage detect level 1.6 2.0 2.2 V
*These parameters are for design reference, not tested.
