SN8P2624
8-Bit Micro-Controller
SONiX TECHNOLOGY CO., LTD Page 89 Version 0.3
1
1
1
1
1
1
OTP PROGRAMMING PIN
11.1.1 EASY WRITER TRANSITION BOARD SOCKET PIN ASSIGNMENT
Easy Writer JP1/JP2 Easy Writer JP3 (Mapping to 48-pin text tool)
VSS 2 1 VDD DIP1 1 48 DIP48
CE 4 3 CLK/PGCLK DIP2 2 47 DIP47
OE/ShiftDat 6 5 PGM/OTPCLK DIP3 3 46 DIP46
D0 8 7 D1 DIP4 4 45 DIP45
D2 10 9 D3 DIP5 5 44 DIP44
D4 12 11 D5 DIP6 6 43 DIP43
D6 14 13 D7 DIP7 7 42 DIP42
VPP 16 15 VDD DIP8 8 41 DIP41
RST 18 17 HLS DIP9 9 40 DIP40
ALSB/PDB 20 19 - DIP10 10 39 DIP39
DIP11 11 38 DIP38
JP1 for MP transition board
DIP12 12 37 DIP38
JP2 for Writer V3.0 transition board
DIP13 13 36 DIP36
DIP14 14 35 DIP35
DIP15 15 34 DIP34
DIP16 16 33 DIP33
DIP17 17 32 DIP32
DIP18 18 31 DIP31
DIP19 19 30 DIP30
DIP20 20 29 DIP29
DIP21 21 28 DIP28
DIP22 22 27 DIP27
DIP23 23 26 DIP26
DIP24 24 25 DIP25
JP3 for MP transition board
11.1.2 WRITER V2.5 AND V3.0 TRANSITION BOARD SOCKET PIN
ASSIGNMENT
GND 2 1 VDD
GND 1 2 VDD CE 4 3 CLK
CE 3 4 CLK OE 6 5 PGM
OE 5 6 PGM D0 8 7 D1
D0 7 8 D1 D2 10 9 D3
D2 9 10 D3 D4 12 11 D5
D4 11 12 D5 D6 14 13 D7
D6 13 14 D7 VPP 16 15 VDD
VPP 15 16 VDD RST 18 17 HLS
RST 17 18 HLS 20 19
Writer V2.5 JP1 Pin Assignment Writer V3.0 JP1 Pin Assignment
 Note: For supporting the body programming, SONIX writer V2.5 must update V3.0 firmware and modify
circuit. Please contact SONIX agent about SONIX Writer V2.5 upgrade.
