8.3.6 TC1 TIMER OPERATION SEQUENCE
TC1 timer operation includes timer interrupt, event counter, TC1OUT and PWM. The sequence of setup TC1 timer is
as following.
) Stop TC1 timer counting, disable TC1 interrupt function and clear TC1 interrupt request flag.
B0BCLR FTC1ENB ; TC1 timer, TC1OUT and PWM stop.
B0BCLR FTC1IEN ; TC1 interrupt function is disabled.
B0BCLR FTC1IRQ ; TC1 interrupt request flag is cleared.
) Set TC1 timer rate. (Besides event counter mode.)
MOV A, #0xxx0000b ;The TC1 rate control bits exist in bit4~bit6 of TC1M. The
; value is from x000xxxxb~x111xxxxb.
B0MOV TC1M,A ; TC1 interrupt function is disabled.
) Set TC1 timer clock source.
; Select TC1 internal / external clock source.
B0BCLR FTC1CKS ; Select TC1 internal clock source.
or
B0BSET FTC1CKS ; Select TC1 external clock source.
) Set TC1 timer auto-load mode.
B0BCLR FALOAD1 ; Enable TC1 auto reload function.
or
B0BSET FALOAD1 ; Disable TC1 auto reload function.
) Set TC1 interrupt interval time, TC1OUT (Buzzer) frequency or PWM duty cycle.
; Set TC1 interrupt interval time, TC1OUT (Buzzer) frequency or PWM duty.
MOV A,#7FH ; TC1C and TC1R value is decided by TC1 mode.
B0MOV TC1C,A ; Set TC1C value.
B0MOV TC1R,A ; Set TC1R value under auto reload mode or PWM mode.
; In PWM mode, set PWM cycle.
B0BCLR FALOAD1 ; ALOAD1, TC1OUT = 00, PWM cycle boundary is
B0BCLR FTC1OUT ; 0~255.
or
B0BCLR FALOAD1 ; ALOAD1, TC1OUT = 01, PWM cycle boundary is
B0BSET FTC1OUT ; 0~63.
or
B0BSET FALOAD1 ; ALOAD1, TC1OUT = 10, PWM cycle boundary is
B0BCLR FTC1OUT ; 0~31.
or
B0BSET FALOAD1 ; ALOAD1, TC1OUT = 11, PWM cycle boundary is
B0BSET FTC1OUT ; 0~15.
) Set TC1 timer function mode.
B0BSET FTC1IEN ; Enable TC1 interrupt function.
or
B0BSET FTC1OUT ; Enable TC1OUT (Buzzer) function.
or
B0BSET FPWM1OUT ; Enable PWM function.
) Enable TC1 timer.
B0BSET FTC1ENB ; Enable TC1 timer.
