Working Instruction Repair Instruction Mechanical/,
Mechanical
1212-7760 State: Preliminary 8.1
Company Internal
© Sony Ericsson Mobile Communications AB
18(66)
2.1.7 Card Reader Assembly
Use the Front Opening Tool to disconnect this BtB
connector which is located on the PBA.
Use the Front Opening Tool to separate the Card Reader
Assembly from the PBA.
Remove the Card Reader Assembly.
To Next Page
