Working Instruction Repair Instruction Mechanical/,
Mechanical
1212-7760 State: Preliminary 8.1
Company Internal
© Sony Ericsson Mobile Communications AB
23(66)
2.1.11 Dome Foil
Use the Flex film Assembly Tool to separate the Dome Foil
from the Keyboard FPC Assembly,
and then have it removed.
T
HE DOME FOIL MUST BE SCRAPPED, CANNOT BE REUSED!
To Next Page
