Working Instruction Repair Instruction Mechanical/,
Mechanical
1212-7760 State: Preliminary 8.1
Company Internal
© Sony Ericsson Mobile Communications AB
56(66)
4.1.6 Card Reader Assembly
THE SHIELD CAN LID HAS GUIDING PINS!
Position the Card Reader Assembly,
and press to attach it to the PBA.
Connect this BtB connector by carefully pressing with your
finger.
