Working Instruction Repair Instruction Mechanical/,
Mechanical
1212-7760 State: Preliminary 8.1
Company Internal
© Sony Ericsson Mobile Communications AB
8(66)
2.1.2 Screw Cover Coated
Slide the Sliding Lens Cover to its end position.
Use the Dentist Hook to remove one of the Screw Cover
Coated,
and do the same on the opposite side.
T
HE TWO SCREW COVER COATED MUST BE SCRAPPED,
CANNOT BE REUSED
!
To Next Page
